Circuits protectedFuse RatingFuse

Front power window (without door control unit)

25A

F29

Ignition switch position II output (van only)5AF30

Not used-F31

Engine control module

15A

F32

Engine control module

10A

F33

Fuel injectors

10A

F34

Filter Heater15AF35

Engine control module (DV6 and Fox engine only)

10A

F36

Active grill shutter (1.6 GTDI and 2.5L engine only)5A

Parking assist control module (van only)

F37

Engine control module

15A

F38

Transmission control module

Not used-F39

Electronic power assist steering

F40

Body control module

20A

F41

Rear window wiper

15A

F42

Heated front seat (wagon only)

15A

F43

Headlamp control module

15A

F44

Heated washer nozzle

10A

F45

Windshield wiper

40A

F46

Heated exterior mirror (without door control unit)7.5AF47

Body control module

25A

F48

Mini fuses

Cartridge fuses

169
