Circuits protectedFuse RatingFuse

Overhead console switch bank

Not used-F61

Autowipers5AF62

Auto-dimming interior mirror

Not used-F63

Not used-F64

Liftgate release10AF65

Front door double locking and unlock relay20AF66

SYNC7.5AF67

Front display interface module

Global positioning system module

Not used-F68

Instrument panel cluster5AF69

Central locking relay20AF70

Heating control head (manual air conditioning)10AF71

Dual automatic temperature control

Steering wheel module7.5AF72

Data link connector7.5AF73

Battery backup sounder

High beam headlamp15AF74

Front fog lamp15AF75

Reversing lamp10AF76

Washer pump20AF77

Not used5AF78

Audio unit15AF79

DVD navigation system

Touchscreen

Hazard flasher switch

Door lock switch

Not used-F80

Power sunroof5AF81

172

Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, Edition date: 07/2013

Fuses
