Protected componentsFuse amp ratingFuse or relay number
Heads-up display.
Voltage stability module.
Not used.—24
Run-start anti-lock brake system.
10A
2
25
Run-start powertrain control module.
10A
2
26
Not used.—27
Not used.—28
Mass air flow monitor.
5A
1
29
Not used.—30
Not used.—31
Electronic fan 1 relay.—32
A/C clutch relay.—33
Not used.—34
Not used.—35
Not used.—36
Not used.—37
Electronic fan 2 relay—38
Electronic fan coil 2 and 3 relay.—39
Horn relay.—40
Not used.—41
Fuel pump coil relay.—42
Not used.—43
Not used.—44
Not used.—45
Not used.—46
Not used.—47
Not used.—48
237
Fusion (CC7) Canada/United States of America, enUSA
Fuses
