Circuits switchedRelay TypeRelay
Intercooler fan.Micro relayR1
Horn.Micro relayR2
Front window defroster (partially heated windscreen).Micro relayR3
Not used.-R4
Rear wiper.Micro relayR5
Not used.-R6
Not used.-R7
Delayed accessory power.Power relayR8
Not used.-R9
Starter relay.Mini relayR10
Air conditioning clutch.Micro relayR11
Cooling fan relay.Power relayR12
Blower motor.Mini relayR13
Powertrain control module.Mini relayR14
Rear window defroster.Power relayR15
Ignition.Power relayR16
204
Focus (CDH) Canada/United States of America, enUSA, First Printing
Fuses
