Passenger Compartment Fuse Box

E129926

Circuits protected

Ampere

rating

Fuse

Fuel pump supply.20AF56

Not used.-F57

Not used.-F58

Passive anti-theft system supply.5AF59

205

Focus (CDH) Canada/United States of America, enUSA, First Printing

Fuses
