ENGINE SPECIFICATIONS

2.5L engine2.0L EcoBoost engine1.5L EcoBoost engineEngine

15212292Cubic inches

Minimum 87 octaneMinimum 87 octaneMinimum 87 octaneRequired fuel

9.7:19.3:110.0:1Compression

ratio

0.049-0.053 in.

(1.25-1.35 mm)

0.027-0.031 in.

(0.70-0.80 mm)

0.025-0.029 in. (0.65-

0.75 mm)

Spark plug gap

Drivebelt Routing

1.5L engine

E167586

2.0L and 2.5L engines

E161383

A. Long drivebelt is on first pulley groove

closest to engine

B. Short drivebelt is on second pulley

groove farthest from engine

MOTORCRAFT PARTS

2.5L Engine2.0L EcoBoost

Engine

1.5L EcoBoost EngineComponent

FA-1912Air filter element

FL-910SOil filter

BXT-90T5-500

BXT-90T5-590

BXT-90T5-500Battery

BXT-90T5-590

BAGM-48H6-760

313

Fusion/Mondeo (CC7) Canada/United States of America, enUSA, First Printing
