Uebler* Rear Bike Carrier F32, for 3 bikes
The available range of high-quality bicycle carriers allow you to take your bikes with you in
a convenient manner.
Very small and lightweight tow bar mounted bike carrier for 3 bikes. Due to its patented
folding system tail lights, bicycle holders and support frame can be easily and completely
folded, the carrier is lockable to the tow bar and bikes are also lockable to the carrier.
Adjustable buckles with long wheel straps for easy fastening of wheels.
Please note: The gross weight mounted on the tow bar (weight of accessory product and
its load together) is not allowed to exceed the permitted nose weight limit
• Dimensions: 770 x 1180 x 790 mm, folded: 250 x 650 x 740 mm
• Maximum bicycle wheel hub distance: 1300 mm
• Weight: 14 kg, including 13 pin adapter.
• Maximum load per rail: 30 kg
• Bike arm suitable for bicycle frames up to a diameter of 75 mm round and 75 x 45 mm
oval
• Suitable for E-Bikes
• Maximum vertical load 54 kg from 75 kg tow bar load and a D-Value 6.7 kN
• Maximum vertical load 35.5 kg under a tow bar load of 75 kg and a D-Value of 6.7 kN
• Maximum vertical load under a D-Value of 6.7 kN or a tow bar load under 50 kg not
permissible
2 007 529
-
Uebler* Rear Bike Carrier F34, for 3 bikes
The available range of high-quality bicycle carriers allow you to take your bikes with you in
a convenient manner.
Very small and lightweight tow bar mounted bike carrier for 3 bikes. Due to its patented
folding system tail lights, bicycle holders and support frame can be easily and completely
folded, the carrier is lockable to the tow bar and bikes are also lockable to the carrier.
Adjustable buckles with long wheel straps for easy fastening of wheels.
Please note: The gross weight mounted on the tow bar (weight of accessory product and
its load together) is not allowed to exceed the permitted nose weight limit
• Dimensions: 1180 x 820 x 710 mm, folded: 610 x 200 x 750 mm
• Maximum bicycle wheel hub distance: 1300 mm
• Weight: 14.5 kg, including 13 pin adapter
• Maximum load per rail: 30 kg
• Bike arm suitable for bicycle frames up to a diameter of 75 mm round and 75 x 45 mm
oval
• Suitable for E-Bikes
• Maximum vertical load 54 kg from 75 kg tow bar load and a D-Value 6.7 kN
• Maximum vertical load 35.5 kg under a tow bar load of 75 kg and a D-Value of 6.7 kN
• Maximum vertical load under a D-Value of 6.7 kN or a tow bar load under 50 kg not
permissible
2 474 458
-
* Warranty covered by third party supplier.
1. Excludes fitting. Recommended Retail Price including VAT.
2. Recommended Retail Price including VAT. Please ask your Ford dealer for additional fitting charges. Please note that supplementary parts may also be
required.
3. Recommended Retail Price including VAT. Please ask your Ford dealer for additional fitting charges. Please note that supplementary parts may also be
required. Price is per alloy and excludes tyre and fitting parts.
4. Recommended Retail Price including VAT. Please ask your Ford dealer for additional fitting and painting charges. Please note that supplementary parts may
also be required.
Prices valid from 18.03.2024. The right is reserved to change prices.
13 FORD C-MAX 04/2015 – Status: 18.03.2024
