Protected componentsFuse amp ratingFuse or relay number
Door control unit rear right25AF7
Not used—F8
Driver seat motor25AF9
Heated rear window25AF10
Not used—F11
Battery electronics control module15AF12
Not used—F13
Charger (C-MAX Energi)10AF14
Not used—F15
Not used—F16
Battery electronics control module10AF17
Battery electronics control module — fan15AF18
Charger fan (C-MAX Energi)15AF19
Not used—F20
Smart datalink connector15AF21
Active noise cancellation10AF22
Not used—F23
DC/AC power converter30AF24
Power liftgate25AF25
AC/DC charger (C-MAX Energi)40AF26
Luggage compartment outlet20AF27
Not used—F28
Not used—F29
Parking aid module5AF30
Rear view camera5AF31
DC/AC power converter5AF32
Not used—F33
206
C-MAX (CCG)
Fuses
