Fuse or relay
number
Fuse amp
rating
Protected components
85 — Not used
86 7.5A* Powertrain control module relay,
Powertrain control module
keep-alive (3.5/3.7L engines)
87 5A* Run/start relay
88 — Run/start relay
89 — Not used
5A* Headlamp leveling motors (China
only)
90 10A* Powertrain control module,
Transmission Control Module
(2.0L engine)
91 10A* Adaptive cruise control (3.5/3.7L
engines)
5A* Automatic transmission warm-up
(2.0L engine)
92 10A* Anti-lock brake system module
93 5A* Blower motor/rear defroster relay
94 30A** Passenger compartment fuse
panel run/start
95 — Not used
96 — Canister purge solenoid diode
(2.0L engine)
97 — Automatic transmission warm-up
diode (2.0L engine)
98 — Air conditioner clutch relay
* Mini Fuses ** Cartridge Fuses
Passenger Compartment Fuse Panel
The fuse panel is located behind a trim panel on the left side of the
driver’s footwell near the parking brake. To remove the trim panel, slide
the release lever to the right then pull the trim panel out.
To remove the fuse panel cover, press in the tabs on both sides of the
cover, then pull the cover off.
Fuses 259
2014 Edge (edg)
Owners Guide gf, 1st Printing, November 2013
USA (fus)
