Replacing license plate lamp bulbs
1. Make sure the headlamp switch is in the off
position.
2. Press the lever and carefully pry the license
plate lamp assembly (located above the license
plate) from the liftgate.
3. Rotate the bulb socket counterclockwise and
remove from lamp assembly.
4. Pull bulb straight out of socket and push in
the new bulb.
5. Install the bulb socket into the lamp
assembly and rotate clockwise.
6. To install, carefully press the lamp assembly
into the liftgate.
BULB SPECIFICATION CHART
Replacement bulbs are specified in the chart below. Headlamp bulbs
must be marked with an authorized “D.O.T.” for North America and an
“E” for Europe to ensure lamp performance, light brightness and pattern
and safe visibility. The correct bulbs will not damage the lamp assembly
or void the lamp assembly warranty and will provide quality bulb burn
time.
Function Number of bulbs
Trade
number
Headlamp high/low beam
(halogen)
2 HIR2
* HID (high intensity
discharge) headlamp
2 D3S
* Front sidemarker lamp N/A LED
Front park/turn signal
lamp
2
3457NAK
(amber)
Rear turn lamp 2
3757NAK
(amber)
