Unbuckle the strap and remove the
jack and tools by pulling the right
side up first. Remove the tools from
the jack in order to remove the
spare tire from under the vehicle.
Note: For some non-cargo management system vehicles, the jack and
tools are located in the right rear of the cargo area behind an access
panel.
Cargo management system (if
equipped):The jack and tools are
located in the right rear of the cargo
area behind an access panel.
To remove jack from vehicle:
1. Release the thumbscrew on the
bracket.
2. Release the retention clip on the
upper part of the jack bracket.
3. Dislodge the jack from the
bracket and carefully guide jack
down and out through trim opening,
upper end out first.
2005 Escape (204)
Owners Guide (post-2002-fmt)
USA_English (fus)
Tires, Wheels and Loading
156
