Item Capacity
Ford Part Name or
equivalent
Ford Part Number / Ford
Specification
Automatic
transmission
(5R55S) fluid
12.7 quarts
(12.0L)
3
Motorcraft
MERCON威 VATF
4
XT-5-QM /
MERCON威 V
Automatic
transmission fluid
(6R80)
12.1 quarts
(11.4L)
3
Motorcraft
MERCON威 LV ATF
5
XT-10-QLV /
MERCON威 LV
Rear axle fluid 3.5 pints (1.7L)
Motorcraft SAE
75W-140 Synthetic
Rear Axle Lubricant
XY-75W140-QL /
WSL-M2C192-A
Front axle fluid
(AWD & 4WD)
2.7 pints (1.3L)
Motorcraft SAE
80W-90 Premium
Rear Axle Lubricant
XY-80W90-QL /
WSP-M2C197-A
Power steering fluid
Fill between the
MIN and MAX
lines on
reservoir
Motorcraft
MERCON威 VATF
XT-5-QM /
MERCON威 V
Transfer case fluid
(4WD)
1.5 quarts
(1.4L)
Motorcraft Transfer
Case Fluid
XL-12 /
—
Transfer case fluid
(AWD)
1.3 quarts
(1.25L)
Windshield washer
fluid
4.2 quarts
(4.0L)
Motorcraft Premium
Windshield Washer
Concentrate
ZC-32-A /
WSB-M8B16- A2
