Fuse or relay
number
Fuse amp
rating
Protected components
38 10A Auto-dimming rearview mirror,
Moonroof
39 15A High beam headlamp shutters
40 10A Rear park lamps, License plate
lamps, Trailer tow park lamps
41 7.5A Overdrive cancel, Tow/haul
42 5A Not used (spare)
43 10A Not used (spare)
44 10A Not used (spare)
45 5A Not used (spare)
46 10A Climate control module
47 15A Fog lamps, left and right turn
signal mirror feed
48 30A Circuit
Breaker
Rear power windows, Passenger
power window, One-touch down
(driver side only), Driver window
switch
49 Delayed
accessory relay
Body control module
Fuses 309
2015 Explorer (exp)
Owners Guide gf, 2nd Printing, September 2014
USA (fus)
