Engine Drivebelt Routing

3.5L / 3.5L V6 EcoBoost engines

2.0L EcoBoost engine

A. Long drivebelt on the first pulley groove closer to the engine

B. Short drivebelt on the second pulley groove farther from the engine

A

B

Capacities and Specifications 385

2015 Explorer (exp)

Owners Guide gf, 2nd Printing, September 2014

USA (fus)
