TECHNICAL SPECIFICATIONS

Item Capacity

Recommended

Fluids and

Lubricants

Ford part number / Ford

specification

Brake fluid

Between MIN and

MAX on reservoir

Motorcraft DOT 4

Low Viscosity High

Performance Motor

Vehicle Brake Fluid

PM-20 /

WSS-M6C65-A2

Hinges, latches, striker

plates and rotors, seat

tracks, fuel filler door

hinge and spring

—

Motorcraft

Multi-Purpose Grease

Spray

XL-5 /

ESB-M1C93-B

Door weatherstrips —

Silicone Spray

Lubricant

XL-6 /

ESR-M13P4-A

Lock cylinders —

Motorcraft

Penetrating and Lock

Lubricant

XL-1 /

None

386 Capacities and Specifications

2015 Explorer (exp)

Owners Guide gf, 2nd Printing, September 2014

USA (fus)
