NOTICE:
Make sure the positive battery terminal cover is in position while removing the negative battery cable clamp to prevent damage from
a short to the positive terminal.
6. Remove the bolt and position the negative aux 12v battery cable aside
•Be sure to cover the battery cable with electrical tape to prevent the cable from making contact with the battery terminal.
Battery High Voltage System Depower
2-5
Section 2: Battery High Voltage System Depower
2020 Explorer / Aviator Hybrid Vehicle Emergency Response Guide - 04/2019
