3-6 High Voltage Charge Cord Lock — Manual Release
Section 3: High Voltage Charge Cord Lock Manual
Release
2020 Explorer / Aviator Hybrid Vehicle Emergency Response Guide - 09/2019
5. Pull outward on the manual release pull-ring to manually retract the High Voltage charge port lock actuator pin. Remove the High Voltage
charge cord from the vehicle.
NOTE:
The pull-ring is red in color.
