(Continued)
5 Driver front door side impact sensor
6 Clockspring
7 Seat position sensors
8 Driver and passenger front impact severity sensors
9 Passenger front door side impact sensor
Item Description
1 Driver seatbelt buckle (includes buckle sensor)
Supplemental Restraint System and Structural Reinforcement — Component Location 4-5
Section 4: Supplemental Restraint System and Structural
Reinforcement — Component Location
2020 Explorer / Aviator Hybrid Vehicle Emergency Response Guide - 04/2019
