Note: Press the required button to switch
the door function off when you open any
door. When the door function is off and you
open a door, the courtesy and door lamps
stay off.
Note: Press the button again to switch the
door function back on. When the door
function is on and you open a door, the
courtesy and door lamps turn on.
Type 1
E230569
Left-hand side map lamp.A.
All lamps on.B.
Door function.C.
Right-hand side map lamp.D.
Type 2
E192153
D D
CA
B
All lamps on.A.
Door function.B.
All lamps off.C.
Map lamps.D.
E187342
All lamps on.A.
Door function.B.
92
F-150 (TFC) Canada/United States of America, enUSA, Edition date: 201607, Second Printing
Lighting
