------------NEW
MODEL
SUPPLEMENT------------
The
release
bearing
hub
support
plate
used
on·
these
new
models
differs
from
that
used
with previous
models
in
that
the
plate
casting
is
filled in and machined to pro-
vide a
supporting
surface
for the
bracket.
Clutch
Pedal, Release
Rod
and
Cron-shaft
Arm
- New
design
pedals
and
release
rods
are
used
oo
these
new
type
models.
The
new
model
pedals
vary
from
those
used
previously
in
that
the
portion below
the
pivot
is
longer
and
set
back
at
a
greater
angle.
The
release
rods for
the
new models are
straight,
where-
as
the
previous
rods
had
a portion which
was
off-set. In
addition,
the
release
rod
used
on
the
new model
Ford
2000 and 3000 with a double
clutch
has
been
increased
in diameter.
The
adjustable
clevis
has
also
been
in-
creased
in
size
to
suit
the
larger
diameter
release
rod.
The
cross-shaft
arm
of
new model
Ford
2000
and 3000
Live
P.T.O.
tractors
is
longer
between
centers
than
that
used
on
previous
models, and
it
has
a different
off-set
to
suit
the new type
release
rod.
Together,
these
changes
enable
the
clutches
to
be
re-
leased
with
less
effort than
was
required on
previous
models.
FOHi)
2000/3000/5000
SINGLE
CLUTCH
-
HELEASE
LINKAGE
Clutch Release Forks - New
release
forks have
been
introduced
that
differ only in
the
material. The fork con-
tacts
pads
are
specially
hardened.
Releose Bearing
Hubs
- New
release
bearing
hubs
with
specially
hardened
faces
at
the
points
of
contact
with
the
release
fork
have
been introduced.
Release Bearing
Hub
Support
Plate -
This
has
been
There
is
no
change
to
the
hub
support
plate
on
the
Ford 5000.
Clutch Pedals, Release
Rods
and
Cross-shaft
Arms
-
New
design
pedals,
release
rods and
cross-shaft
arms
are
used
on
the
new model Ford 2000 and 3000
tractors
with a
single
clutch
and on the new model Ford 5000.
Each
of
the
new
pedals
is
longer below
th!;!
pivot
point
and
the
lower
end
is
set
back
at
a
greater
angle.
On
the
new model
Ford
2000 and 3000
tractors
with a
single
clutch,
the
clutch
release
rod
is
straight
compared
to
the
off-set
design
of
the
previous rod. It
is
also
longer
than
the
previous
rod,
'as
is
the
new
release
rod
used
on
the
Ford 5000.
The
cross-shaft
arm
of
the
Ford 5000
is
unchanged,
but
on
the
new model
Ford
2000 and 3000
tractors
with a
single
clutch,
a new
arm
is
used
which
has
a
different
off-set
to
the
previous
arm.
CLUTCH
PEDAL
ADJUSTMENT
Regular
checks
on
clutch
pedal free play
is
very im-
portant. Recommendations are
that
this
check
be
made
at
intervals
of
50 hours
of
operation,
NOTE:
This 50
hour
check is
now
recommended
lor pre-
vious 2000, 3000, 4000 and 5000 tractors as
well
as on
the new model tractors.
Because
of
linkage
changes,
the
free
play
specified
for new models,
see
following
table,
differs
from
that
specified
for
previous
models.
Clutch Pedal
Free
Play -
New
Model
Tractors
Ford
2000/3000 with
Transmission
P.T.O.
1.12-1.38
in.
(28-35
mm)
Ford 2000/3000 with
Live
P.T.O.
1.38-1.63
in.
(35-41
mm)
changed for new model Ford 2000 and 3000
tractors
with Ford 4000 with
Transmission
P.T.O.
1.25-1.50
in.
(32-38
mm)
a
single
clutch
to commonize with
the
support
plate
used
on
new model Ford 2000 and 3000
tractors
with a
double
clutch. As
the
leaf
spring
type
of
release
mechanism
is
Ford 4000 with
Independent
P.T.O.
not
used
on
these
models,
there
is
no
necessity
for a
spring fulcrum bracket;
hence
the
change
to
the
hub
sup-
Ford
5000
port
plate
is
of
no
significance
in
service.
PAGE 10
1.62-1.88
in.
(41-48
mm)
1.25-1.50
in.
(32-38
mm)
