Ford Pro - Anchor Bolt Dimensions and Spacing

!"##$%!&'()*"+,+)
*"-$%)$($!,%".&!+)
#!"
*%$*'%',&".)8"%)&.+,'((&.E),1$)$B0&*#$.,)
)
)
A B C D E F G H I J K L M Ø
mm
41,
5
360
77,
4
290
70
110
549
33
22
4
95
10
0
317,
4
160
20
inch
1.6
3
14.17
3.0
5
11.42
2.7
6
4.3
3
21.6
1
1.3
0
8.8
2
3.7
4
3.9
4
12.5
0
6.3
0
0.7
9
It is recommended to use an expansive anchoring M16 x 145mm (5/8” x 5.71 inches), brand
Index, model MTP; with a tightening torque of 120 Nm (manufacturer’s recommendation).
The minimum distance from
the screws to the edge of the base is M = 160mm (6.3 inches)
and minimum length h
min
is 300mm (11.81
inches).
Ford Pro contact info: chargingsupport@fordpro.com and 1-800-34-FLEET
NB COMMERCIAL POST Installation Manual Revision 1.5
