Ford Motor Company
12 | VCM3 | Operationen
If you have the need to reset your Point-to-Point
pairing, you can use the following steps.
1. Click the Wireless Network icon in your
Windows taskbar.
• A list of the available wireless networks in
range of your computer is displayed.
2. Choose "Network and Internet Settings".
3. Choose "Wi-Fi" from the left column.
4. Under "VCM3", choose "Manage Known
Networks".
5. Click on a VCI in the list and choose
“Forget” to remove your stored Point-to-
Point network. The name will contain VCI
and the last 8 digits of VCM3 serial number,
(VCIxxxxxxxx).
6. When you disconnect, then reconnect VCM3
to the computer using the USB connecting
cable, a new pairing will be established with
the VCI.
5.4.2 Activating the WLAN link via an access
point
VCM3 is capable of communicating on your
workshop network over Wireless. The "Network
Setup" tab in the "VCI Manager" software
provides a number of functions used to select
and configure VCM3 network connection
interfaces, including wireless access and
security settings.
i You must be connected to the VCM3 via
USB to access the settings on the "Network
Setup" tab. If you are not connected via USB,
the controls on the "Network Setup" tab are
disabled.
The VCM3 can be configured to connect via an
access point. The following must be prepared
before configuring:
• An IP address and subnet mask that can be
assigned to the VCM3 (if the existing LAN
does not assign IP addresses automatically)
• A wireless network access point SSID
(network name)
• Network security standard WPA2 enabled
• Data encryption via TKIP or WEP (64-bit or
128-bit)
• WLAN password
The figure below shows several VCM3s that are
connected to a single computer via a wireelss
access point.
