• Original operating instructions
• Safety information
3. Intended use
The pole-mounted petrol-powered pruner is
suitable for extensive sawing work, felling trees
or sawing any materials other than wood.
The equipment may be used only for its intended
purpose. Any other use is deemed to be a case
of misuse.
The user/operator and not the manufacturer will
be liable for any damage or injuries of any kind
which result from such misuse.
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be
voided if the equipment is used in commercial,
trade or industrial businesses or for equivalent
purposes.
4. Technical data
Engine type: 2-stroke engine,
air-cooled, chrome cylinder
Engine power (max.): 0.85 kW/ 1.14 HP
Displacement: 32.6cc
Engine idle speed: 3400 RPM
Max. engine speed: 10500 RPM
Max. cutting length: 9.8”
Weight with cutter bar and chain: 16.7 LB.
Chain: 10”, 3/8”, 0.050”
10”, 3/8”, 0.050”
Cutter bar:
Ignition: Electronic
Drive: Centrifugal clutch
Tank capacity: 28 oz.
Spark plug: L7T
Sound and vibration
L
pA
sound pressure level: 93,9 dB(A)
K
pA
uncertainty: 2,5 dB
L
WA
sound power level: 108,2 dB(A)
K
WA
uncertainty: 2,5 dB
2. Layout and items supplied
2.1 Layout
1. Cutter bar
2. Saw chain
3a. Oil tank / cap
3b. Gear unit
4. Drive rod mechanism
5. Connecting piece
6. Additional handle
7. Eyelet
8. Handle
10. Throttle lock
11. Throttle lever
12. Spark plug boot
13. Starter cable
14. Petrol tank / cap
16. Choke lever
17. Clip
18. Screw (4x)
19. Open-ended wrench size 8/10
20. Allen key
21. Cutter guard
22. Carrying strap
23. Oil/petrol mixing bottle
24. Multifunction tool
25. Lubrication nipple
26. Fuel pump “primer“
2.2 Items supplied
• Open the packaging and take out the
equipment with care.
• Remove the packaging material and any
packaging and/or transportation braces (if
available).
• Inspect the equipment and accessories for
transport damage.
• If possible, keep the packaging until the end
of the guarantee period.
Important!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
For Customer Service:
Please call 877-713-3189 (Toll Free), or email: Support@fot-usa.com
9
• Check to see if all items are present.
