Forest-Master FM13WC - Page 17

Ref.No. Description Ref.No. Description
1 foundation 29 Lower blade
2 Wheel axis 31 Engine
3 Blade 38 M10*24 hex bolt
4 wheel 39
Φ
25 washer
5 Belt cover inner plate 40 M25 open nut
6 clutch 41 Pin
7 bearing 42 M10 lock nut
8 pulley 43 M10*80 hex bolt
9 42*9*5 spacer 44 Switch
10 Belt cover 45 Switch cover
11 Bearing fixation frame 46 M6*60 socket head screw
12 roller 47 Switch frame
13 Rubber pad 48 Rubber of feeder
14 Support feet 49 Rubber fitting
15 Bolt pin 50 M6*16 hex bolt
16 B-shape Pin 51
Φ
12 washer
17 Feet fixation 52
Φ
16*80*1.5 spring
18 Tow bar 53 M12 nut
19 Tow hitch 54 M8*12 hex bolt
20 Discharge 55 Discharge knob
21 Chute adjust 58 Discharge to frame rubber
22 Engine fixation 59 Feed to frame rubber
23 In-feed 60 Bearing
24 Belt 61 Flange
28 chain 62 Bearing cover
16
