11
No. Parts No. Descripon Remark
1 FD8732HS B 001 PAPER CUTTER ASS'Y
1SET
2 FD8732HS B 002 CD1 CUTTER ASS'Y
1SET
3 FD8732HS B 003 CD2 CUTTER ASS'Y
1SET
4 FD8732HS B 004 FRONT PLATE
SGHC / 1EA / 3.0t
5 FD8732HS B 005 MOTOR BASE PLATE
SS400 / 1EA / 8.0t
6 FD8732HS B 006 SPACE PIPE
SS400 / 4EA / 10Ax100
7 FD8732HS B 007 SHAFT SPROCKET
S45C / 1EA / #60/Z19
8 FD8732HS B 008 MOTOR SPROCKET
S45C / 1EA / #60/Z19
9 FD8732HS B 009 CHAIN
1EA / #60/44Link
10 FD8732HS B 010 GEAR COVER
ULETHANE / 1EA / 1.0t
11 FD8732HS B 011 MOTOR
1EA / 1HP(100:1)
COMPLETE CUTTING BLOCK ASSEMBLY
