Formax FD 8732HS - Page 15

15
No. Parts No. Description Remark
1 FD8732HS D 001 CD1 SIDE PLATE (R) SS400 / 1EA / 5.0t
2 FD8732HS D 002 CD1 SIDE PLATE (L) SS400 / 1EA / 5.0t
3 FD8732HS D 003 CD1 SHAFT (L) S45C / 1EA / HEX. 32
4 FD8732HS D 004 CD1 SHAFT (S) S45C / 1EA / HEX. 32
5 FD8732HS D 005 CD GUIDE POST S45C / 4EA / Ø12
6 FD8732HS D 006 CUTTER SK5 / 280±3 / 0.78t
7 FD8732HS D 007 RING SPHC / 280±3 / 0.8t
8 FD8732HS D 008 GUIDE SGHC / 280±3 / 0.6t
9 FD8732HS D 009 CD1 GUIDE PLATE(L/R) SGHC / 2EA / 3.0t
10 FD8732HS D 010 CD CPACE RING SGHC / 2EA / 3.0t
11 FD8732HS D 011 CD SPACE RING (HEX) ACETAL / 4EA / 5.0t
12 FD8732HS D 012 NR BEARING 3EA / 62/28Z
13 FD8732HS D 013 BEARING 2EA / 6005ZZ
14 FD8732HS D 014 CD BEARING WASHER 2EA / AW06
15 FD8732HS D 015 CD BEARING NUT 2EA / AN06
16 FD8732HS D 016 CD1 BEARING PLATE SS400 / 2EA / 5.0t
17 FD8732HS D 017 CD1 SPUR GEAR S45C / 2EA / M=3/Z=20
18 FD8732HS D 018 CD1-PAPER GEAR (A) S45C / 2EA / M=4/Z=28
19 FD8732HS D 019 CD1 OIL PIPE ASS'Y 1EA
20 FD8732HS D 020 CD TOP SIDE PLATE SS400 / 1EA / 5.0t
21 FD8732HS D 021 CD-SPACE RING 1 SS400 / 1EA / Ø45 x 10.5
22 FD8732HS D 022 CD-SPACE RING 2 ACETAL / 1EA / Ø33.5 x 3
CD/DVD 1 CUTTING BLOCK ASSEMBLY
