Formula Linea - Cassette Mounting and Removing; Mounting Cassette; Removing Cassette

14
-Starting from the valve, pull the tire until it comes off the rim and continue around
the entire wheel circumference removing the tire.
CAUTION: Completely remove one side of the tire before going on to the oth-
er side.
-Carry out the same operation on the other side of the tire.
-Remove the tire.
3 MOUNTING AND REMOVING
THE CASSETTE
3.1 Mounting HG 9/10/11/12
SHIMANO INC. – PG 9/10/11/12
SRAM CORP
-Fit the cassette (12) onto the free-
hub body (13) following the cassette
manufacturer’s instructions for
proper alignment.
-Use tool (14) (TL – LR15 from
Shimano Inc. or FR5 from Park Tool
Co.) to tighten the lock ring (15) sup-
plied with the cassette on the free-
hub body to the correct torque spec-
ified by the cassette manufacturer.
3.2 Removing HG 9/10/11/12
SHIMANO INC. – PG 9/10/11/12
SRAM CORP
-Remove lock ring (15) using tool (14)
(TL-LR15 from Shimano Inc. or FR-5
from Park Tool Co.) and a chain whip
(16).
-Remove the cassette from the free-
hub body.
16
15
12
14
13
12
