8
WARNING: Never drill the rim for a larger valve hole or try to redrill the rim.
The rim will be irreparably damaged and may even collapse as a result.
-Place the partially inflated inner tube (5) completely inside the tire. The Presta valve
should be inserted in the hole in the rim. Place the tube in the center of the tire
casing.
-
Insert the other tire bead (6), forcing it in the rim groove. Start from the point opposite
the valve and continue along the entire circumference of the rim. Use tire levers if
necessary. Be careful not to pinch the inner tube (5).
WARNING: Do not use screw
drivers or other sharp tools
that may scratch or damage
the edge of the rim or punc-
ture the inner tube.
- Inflate the inner tube (5) until the
two tire beads (4-6) are secured in
the correct position.
WARNING: Even when using an inner tube, it is EXTREMELY important to
seat the two tire beads to prevent the tire from coming off the rim.
5
6
6
4
5
