Formula T1 - Assembly; Brake Disc Installation

22
1 ASSEMBLY
1.1 Brake disc installation
WARNING! DO NOT TRY TO DISASSEMBLE OR ATTEMPT TO MODIFY THIS NEW
FORMULA SRL PRODUCT!
Serviceonthisproductmustbeperformedonlybyqualifiedprofessionalme-
chanics who are familar with and understand the technical details of how this
product works.
If you decide to ignore this important safety warning, you are doing so at your
ownriskandatnolegalliabilitytoFORMULASRLoritsdistributors.
WARNING: ConsultTHESAFETYREGULATIONSfoundinthismanual(pp.16-17-18).
CAUTION: Fordiscinstallation,useadynamometric(Torque)wrenchsuitableforthe
given tightening torque.
WARNING: Ensurethediscrotorisn’thotbeforeworkingonitbylettingitsitforamini-
mumof10-15minutes.Letitcoolifnecessary.
CAUTION: Whenremovingthescrews,alwaysmakesuretoreapplymediumstrength
Loctite®andensurethetorquesettingsarecorrectbyusingatorquewrench.
TherangeofFORMULAdiscbrakesincludesthefollowing
models:
I.S. MONOLITHIC BRAKE DISC
Place brake disc 1(withthemarkingsfacingoutwards)on
hub 2ofanassembledwheel.Makesurethearrowonthe
discindicatesthecorrectdirectionofrotation.Tightenthe6
screws supplied 3 withaTORX®T25bit/tool.Tightenthe
6screwsinastarpatterntoatorquesettingof6Nm±5%.
Carefully clean the disc with isopropyl alcohol to remove
anytracesofgreaseoroil.Mountthewheelandsecurewith
the original fasteners.
I.S. TWO PIECE BRAKE DISC
Place brake disc 1(withthemarkingsfacingoutwards)on
hub 2ofanassembledwheel.Makesurethearrow4 on
the disc flange indicates the correct direction of rotation.
Tightenthe6MSscrews3suppliedwithaTORX
®
T25bit/
tool.Tightenthe6screwsinastarpatterntoatorquesetting
of 6Nm±5%. Carefully clean the disc with isopropyl alcohol
toremoveanytracesofgreaseoroil.Mountthewheeland
secure with the original fasteners.
3
2
1
3
2
1
4
