Fortinet 40F Series User Manual

12 13
English
Front - FG/FWF 60F Series Rear - FG/FWF 60F Series
4
4
2
2
3
3
5
5
6
6
1
1
 passive directional WiFi antenna connection
 1 Gbps Ethernet connections
(FortiWiFi models only)
Power 12V DC, 100-240V AC 50/60Hz adapter
 CLI management computer interface
1 Gbps Ethernet interface
1 Gbps Ethernet interfaces
 1 Gbps Ethernet FortiLink auto-detect connections
7
 USB 3.0 server port
7
8
8
A B
60F
2
3
6
5
4
1
FortiGate
Green: The device is on
Off: The device is off
Green: Power is on
Off: Power is off
: FortiLink interfaces
Green: Normal
Flashing Green: Booting up
LOGO
PWR
STATUS
HA
PORT
LINK/ACT
WIFI
PORT
SPEED
FortiLink
4
Green: Operating in an HA cluster
Amber: HA failover
Off: Not in an HA cluster
Green: Connected at 1Gbps
Amber: Connected at 100Mbps
Off: Not connected or 10Mbps
Green: Connected
Flashing Green: Transmitting data
Off: No link established
Green: WiFi connected
Flashing Green: WiFi activity
Off: WiFi is off
1
2
3
6
75
7
FortiWiFi
Blue: The device is on
Off: The device is off
(FortiWiFi models only)
(FortiWiFi models)
(FortiGate models)

Fortinet 40F Series Specifications

General

Form Factor	Desktop
Power Supply	External
Operating Temperature	0°C to 40°C
Humidity	10% to 90% non-condensing
USB Ports	1 x USB Port
