- 397 -
Command Mode
Privileged EXEC
User EXEC
Display Message
Rule Number: The ordered rule number identifier defined within the IPv6 ACL.
Action: The action associated with each rule. The possible values are Permit or Deny.
Match All: Indicates whether this access list applies to every packet. Possible values are True or
False.
Protocol: The protocol to filter for this rule.
Source IP Address: The source IP address for this rule.
Source L4 Port Keyword: The source port for this rule.
Destination IP Address: The destination IP address for this rule.
Destination L4 Port Keyword: The destination port for this rule.
IP DSCP: The value specified for IP DSCP.
Flow Label: The value specified for IPv6 Flow Label.
Log: Displays when you enable logging for the rule.
Assign Queue: The queue identifier to which packets matching this rule are assigned.
Mirror Interface: The slot/port to which packets matching this rule are copied.
Redirect Interface: The slot/port to which packets matching this rule are forwarded.
7.23.2 Configuration Commands
7.23.2.1 ipv6 access-list
This command creates an IPv6 Access Control List (ACL) identified by <name>, consisting of
classification fields defined for the IP header of an IPv6 frame. The <name> parameter is a
case-sensitive alphanumeric string from 1 to 31 characters
uniquely identifying the IPv6 access list.
If an IPv6 ACL by this name already exists, this command enters IPv6-Access-List config mode to allow
updating the existing IPv6 ACL.
Syntax
ipv6 access-list <name>
no ipv6 access-list <name>
<name> - access-list name up to 31 characters in length.
no - This command deletes the IPv6 ACL identified by <name> from the system.
