Fortinet FortiGate 30E User Manual

FortiGate 30E
CONSOLE WAN 4 3 2 1DC+12V
Power
12V DC
100-240V AC, 50-60Hz adapter
WAN Port (RJ-45)
Gigabit Ethernet port for
Internet connection
Internet
Console (RJ-45)
Optional connection to the
management computer
Provides access to the CLI
FortiGate 30E
PWR STA ALARM HA
1 2 3 4 WAN
SPEED
LINK/ACT
USB
Ethernet Ports Link/Act
Green: Connected
Flashing Green: Transmitting & receiving data
Off: No link established
Ethernet Ports Speed
Green: Connected at 1Gbps
Amber: Connected at 100Mbps
Off: Not connected or connected at 10Mbps
USB (USB A)
USB 3.0 server port
PWR
Green: The unit is on
Off: The unit is off
STA
Green: Normal
Flashing Green: Booting up
Red: The unit has a major alarm
ALARM
Red: The unit has a major alarm
Amber: The unit has a minor alarm
Off: The unit is operating normally
HA
Green: Operating in an HA cluster
Red: HA failover
Off: Not in an HA cluster
Logo
Green: The unit is on
Off: The unit is off
Ethernet Ports 1 - 4 (RJ-45)
Gigabit Ethernet ports for local
network connection

Fortinet FortiGate 30E Specifications

General

Brand	Fortinet
Model	FortiGate 30E
Category	Network Router
Language	English
