Fortinet FortiGate 80F Series User Manual

1716
FWF-81F-2R-POE
2
3
5
1
FortiWiFi 81F-2R
Blue: The device is on
Off: The device is off
Green: Both power supplies are functioning
Amber: One power supply is functioning
Off: Power is off
LOGO
PWR
WIFI
STATUS
HA
SFP/WAN
MAX PoE
BLE/RESET Restores factory default and BLE settings
Ports
4
6
Green: Operating in an HA cluster
Amber: HA failover
Off: Not in an HA cluster
Flashing Green: 1000M/100M/10M data activity
Off: No link established
Flashing Green: 1000M/100M/10M data activity
Off: No link established
Green: Operating normally; BLE is off
Flashing Green: Booting up
Flashing Amber: BLE is on
Front Panel - FWF 81F-2R-POE
41 2
6
3 5
(WAN & SFP
are Shared Ports)
LINK/ACT
PoE
Green: WiFi connected
Flashing Green: WiFi activity
Off: WiFi is off
HAPWR
WAN1
WAN2
5 6
SFP1
PoE
PoE
SFP2
MAX
PoE
LINK/ACT
4321
A B
STATUS
81F-2R-PoE
WiFi
BLE / RESET
Red: Providing Max PoE Power
Off: PoE power available
Green: PoE power on
Off: PoE power off
