Fortinet FortiGate 80F Series User Manual

1514
FWF-81F-2R-POE
QuickStart Guide
FortiWiFi-81F-2R-POE
Box Includes - FWF 81F-2R-POE
Wall Mount Hardware
(Not included, sold separately)
Wall Mount Kit
(Not included, sold separately)
Ethernet Cable
HAPWR
WAN1
WAN2
5 6
SFP1
PoE
PoE
SFP2
MAX
PoE
LINK/ACT
4321
A B
STATUS
81F-2R-PoE
WiFi
BLE / RESET
3 WiFi Antennas
Back Panel - FWF 81F-2R-POE
6
5
4
7
3
2
1
Power Input 54V DC 2.78A, 100-240V AC 50/60Hz
(optional redundant power adapter and cable available for purchase)
Console (RJ-45) CLI management computer interface
Ports 1 to 6 (RJ-45) 1 Gbps Ethernet interface
FortiLink Ports A & B (RJ-45) 1 Gbps Ethernet interface
SFP Shared Ports 1 & 2 (SFP) 1 Gbps SFP interface
WAN Shared Ports 1 & 2 (RJ45) 1 Gbps Ethernet interface
6
7
USB (USB A) USB 3.0 server port
54
54
SFP 1 WAN 1
WAN 2
1
2 4 6 B
3 5 A
SFP 2
– shared –
– shared –CONSOLE
USB
WiFi WiFi SCAN
3 4
1 2
5
Antenna Connection (SMA) passive directional antenna connection
54V DC Power AdapterPower Cable
