Fortinet FortiGate 80F Series User Manual

1312
FWF-80F-2R Series
2
3
5
1
FortiWiFi 81F-2R
Blue: The device is on
Off: The device is off
Green: Both power supplies are functioning
Amber: One power supply is functioning
Off: Power is off
LOGO
POWER
WIFI
STATUS
HA
PORT
LINK/ACT
WAN
BLE/RESET Restores factory default and BLE settings
SFP
4
6
Green: Operating in an HA cluster
Amber: HA failover
Off: Not in an HA cluster
Flashing Green: 1000M/100M/10M data activity
Off: No link established
Flashing Green: 1000M/100M/10M data activity
Off: No link established
Flashing Green: 1000M/100M/10M data activity
Off: No link established
Green: Operating normally; BLE is off
Flashing Green: Booting up
Flashing Amber: BLE is on
Front Panel - FWF 80F-2R Series
41 2
6
3 5
(WAN & SFP
are Shared Ports)
Green: WiFi connected
Flashing Green: WiFi activity
Off: WiFi is off
HA
POWER
WAN1
WAN2
A
B
SFP1
SFP2
1
2
3
4
5
6
STATUS
81F-2R
WiFi
BLE / RESET
