Fortinet FortiGate 80F Series User Manual

1110
FWF-80F-2R Series
QuickStart Guide
FortiWiFi-80F/81F/-2R
Box Includes - FWF 80F-2R Series
Wall Mount Hardware
(Not included, sold separately)
Wall Mount Kit
(Not included, sold separately)
Ethernet Cable
HA
POWER
WAN1
WAN2
A
B
SFP1
SFP2
1
2
3
4
5
6
STATUS
81F-2R
WiFi
BLE / RESET
3 WiFi Antennas
Back Panel - FWF 80F-2R Series
6
5
4
7
3
2
1
Power Input 12V DC 5A, 100-240V AC 50/60Hz
(optional redundant power adapter and cable available for purchase)
Console (RJ-45) CLI management computer interface
Ports 1 to 6 (RJ-45) 1 Gbps Ethernet interface
FortiLink Ports A & B (RJ-45) 1 Gbps Ethernet interface
SFP Shared Ports 1 & 2 (SFP) 1 Gbps SFP interface
WAN Shared Ports 1 & 2 (RJ45) 1 Gbps Ethernet interface
6
7
USB (USB A) USB 3.0 server port
SFP 1 WAN 1
WAN 2
1
2 4 6 B
3 5 A
SFP 2
– shared –
– shared –CONSOLE
USB
WiFi WiFi SCAN
3 4
1 2
5
Antenna Connection (SMA) passive directional antenna connection
12V DC Power AdapterPower Cable
