39
Fortress S-Series
15.2 MODEL: FORTRESS S425
ISO 7176-15 MIN. MAX. COMMENTS
OVERALL LENGTH 1345 mm 1345 mm STANDARD CONFIGURATION
OVERALL WIDTH 655 mm 655 mm STANDARD CONFIGURATION
TOTAL MASS (WITH BATTERIES) 117 kg 117 kg STANDARD CONFIGURATION
MASS OF THE HEAVIEST PART - 35 kg SEAT
STATIC STABILITY DOWNHILL - 8° 150 KG USER
STATIC STABILITY UPHILL - 8° 150 KG USER
STATIC STABILITY SIDEWAYS - 8° 150 KG USER
ENERGY CONSUMPTION (MAX. RANGE) - 25 km TO ISO 7176-4 (SEE SECTION 9.13)
DYNAMIC STABILITY UPHILL - 8°-18% 150 KG USER
OBSTACLE CLIMBING - 50 mm STANDARD CONFIGURATION
RAMP TRANSITION 8° 8° WITHOUT HIGH CENTERING
MAX. SPEED FORWARD 12 kph/8 mph STANDARD CONFIGURATION
MIN. BRAKE DISTANCE FROM MAX. SPEED - 4 m WITH STANDARD PROGRAMMING
MAX. SPEED REVERSE - 50% % OF FORWARD SPEED
EFFECTIVE SEAT DEPTH 490 mm STANDARD CONFIGURATION
EFFECTIVE SEAT WIDTH 490 mm STANDARD CONFIGURATION
SEAT SURFACE HEIGHT 447 mm 497 mm TO SCOOTER FLOOR (3 POSITIONS)
BACK REST ANGLE -70° 60° FROM VERTICAL
BACK REST HEIGHT 525 mm STANDARD CONFIGURATION
FORE / AFT SEAT ADJUSTMENT +100 mm FROM REAR MOST POSITION
SEAT WEIGHT WITH SLIDE 35 kg STANDARD CONFIGURATION
TOP OF ARM REST TO SEAT 230 mm ARM REST SET AT 90°
MIN. TURNING RADIUS 3.03 m STANDARD CONFIGURATION
MIN. TURN BETWEEN WALLS 1.98 m STANDARD CONFIGURATION
NOMINAL BATTERY VOLTAGE 24V 24V TWO 12V BATTERIES
REVERSING WIDTH 1.98 m
ADDITIONAL SPECIFICATIONS MIN. MAX. COMMENTS
MAXIMUM POTENTIAL RANGE 42 km INDUSTRY BENCHMARK (SECTION 9.15)
CONTROLLER CUT-OFF VOLTAGE 16V DRIVE STOPS
BATTERY CAPACITY 55Ah 55Ah SEE OPTIONS
BATTERY FUSIBLE LINKS - 100A IN-LINE FUSE ON EACH BATTERY
BATTERY CHARGER LOOM FUSIBLE LINK - 15A
BATTERY CHARGER 8A 8A AUTOMATIC CYCLIC
MAX. CURB HEIGHT 50 mm
GROUND CLEARANCE 60 mm
REAR SUSPENSION TRAVEL 11 mm UNLADEN
FRONT SUSPENSION TRAVEL 23 mm UNLADEN
REAR WHEEL DRIVE - - 4 WHEEL SCOOTER
SCOOTER PUSH FORCE 100N IN FREE-WHEEL
CRASH TESTED NO
TIRE PRESSURE 40psi
