40
Fortress S-Series
15.3 MODEL: FORTRESS S700
ISO 7176-15 MIN. MAX. COMMENTS
OVERALL LENGTH *1500 mm *1500 mm STANDARD CONFIGURATION
OVERALL WIDTH 657 mm 657 mm STANDARD CONFIGURATION
TOTAL MASS (WITH BATTERIES) 145.5 kg 145.5 kg STANDARD CONFIGURATION
MASS OF THE HEAVIEST PART - 35 kg SEAT
STATIC STABILITY DOWNHILL - 10° 160 KG USER
STATIC STABILITY UPHILL - 10° 160 KG USER
STATIC STABILITY SIDEWAYS - 10° 160 KG USER
ENERGY CONSUMPTION (MAX. RANGE) - 35 km TO ISO 7176-14 (SEE SECTION 9.13)
DYNAMIC STABILITY UPHILL - 10°-18% 160 KG USER
OBSTACLE CLIMBING - 100 mm STANDARD CONFIGURATION
RAMP TRANSITION 18° 18° WITHOUT HIGH CENTERING
MAX. SPEED FORWARD 15 kph STANDARD CONFIGURATION
MIN. BRAKE DISTANCE FROM MAX. SPEED - 6 m WITH STANDARD PROGRAMMING
MAX. SPEED REVERSE - 50% % OF FORWARD SPEED
EFFECTIVE SEAT DEPTH 490 mm STANDARD CONFIGURATION
EFFECTIVE SEAT WIDTH 490 mm STANDARD CONFIGURATION
SEAT SURFACE HEIGHT 450 mm 500 mm TO SCOOTER FLOOR (3 POSITIONS)
BACK REST ANGLE -70° 60° FROM VERTICAL
BACK REST HEIGHT 525 mm STANDARD CONFIGURATION
FORE / AFT SEAT ADJUSTMENT +30 mm FROM REAR MOST POSITION
SEAT WEIGHT WITH SLIDE 35 kg STANDARD CONFIGURATION
TOP OF ARM REST TO SEAT 230 mm ARM REST SET AT 90°
MIN. TURNING RADIUS 2950 mm STANDARD CONFIGURATION
MIN. TURN BETWEEN WALLS 2250 mm STANDARD CONFIGURATION
NOMINAL BATTERY VOLTAGE 24V 24V TWO 12V BATTERIES
REVERSING WIDTH 2250 mm
ADDITIONAL SPECIFICATIONS MIN. MAX. COMMENTS
MAXIMUM POTENTIAL RANGE 55 km INDUSTRY BENCHMARK (SECTION 9.15)
CONTROLLER CUT-OFF VOLTAGE 16V DRIVE STOPS
BATTERY CAPACITY 55Ah 75Ah SEE OPTIONS
BATTERY FUSIBLE LINKS - 100A IN-LINE FUSE ON EACH BATTERY
BATTERY CHARGER LOOM FUSIBLE LINK - 15A
BATTERY CHARGER 8A AUTOMATIC CYCLIC
MAX. CURB HEIGHT 100 mm
GROUND CLEARANCE 100 mm 130 mm
REAR SUSPENSION TRAVEL 50 mm UNLADEN
FRONT SUSPENSION TRAVEL 40 mm UNLADEN
REAR WHEEL DRIVE - - 4 WHEEL SCOOTER
SCOOTER PUSH FORCE 100N IN FREE-WHEEL
CRASH TESTED NO
TIRE PRESSURE 40psi
* Exceeds recomended dimensions.
