Fortress Technologies Ultra Quiet Series User Manual

Page 14 For technical questions, please call 1-888-866-5797. Item 57336
SAFETY OPERATION MAINTENANCEINSTALLATION
Parts List and Diagram
Parts List
Part Description Qty
1 Bolt M4×12 8
2 Washer 8
3 End Cover 2
4 Retainer Ring 2
5 Fan 1
6 Crank Saft 2
7 Bolt M8×8 4
8 Bearing 2
9 Connecting Rod 2
10 Bolt M5×20 2
11 Bolt M5×132 4
12 Spring Washer 4
13 Washer 4
14 Rubber Cushion 4
15 Crank Case 2
16 Cable Bracket 1
17 Washer 10
18 Bolt M4×5 2
19 Wire Clip 1
20 Wire 1
21 Nut M4 1
22 Locking Washer 1
23 Bolt M4×12 1
24 Bearing 2
25 Stator Sleeve 1
26 Stator Assembly 1
27 Flat Key 2
28 Rotor Assembly 1
29 Plug 1
30 Nut M5 4
31 Fan 1
32 Piston Ring 2
33 Press Block 2
34 Washer 2
35 Bolt M6×16 2
36 Gasket 2
37 Cylinder 2
38 Cylinder Seal 2
39 Bolt M4×6 2
40 Reed Valve 4
41 Valve Plate 2
42 Reed Valve Limit Block 2
43 Bolt M4×8 6
44 Cylinder Head Seal 2
45 Cylinder Cap 2
46 Washer 8
47 Spring Washer 8
48 Bolt M6×70 8
49 T-Cock 1
50 Easy-Start Valve 1
51 Seal 4
52 Tube 2
Part Description Qty
53 Cylinder Head Guard Limit Block 2
54 Cylinder Head Guard 2
55 Screw 4
56 Air Filter 2
57 Soft Pipe 2
58 Tank Assembly 1
59 Bolt M12×80 2
60 Washer 4
61 Wheel 2
62 Wheel Axle Sleeve 2
63 Nut M12 2
64 Nut M6 2
65 Rubber Foot 2
66 Washer 12
67 Bolt M6×20 2
68 Drain Valve 1
69 Nut M8 4
70 Bolt M6×14 10
71 Bolt M8×30 4
72 Nut M8 4
73 Cap Nut M8 4
74 Funnel 2
75 Tube Nut 1
76 Exhaust Pipe 1
77 Tube Nut 1
78 Power Switch 1
79 Power Cord 1
80 Handle Grip 1
81 Frame Assembly 1
82 K Nut 8
83 Outlet Pipe 1
84 Tube Nut 2
85 Funnel 2
86 Bushing 2
87 Elbow 2
88 Safety Valve 1
89 Pressure Regulator 1
90 Tank Pressure Gauge 1
91 Outlet Pressure Gauge 1
92 Air Outlet 2
93 Plug 3
94 Panel 1
95 Capacitor Case 1
96 Capacitor 1
97 O-Ring 2
98 Bottom Plate 1
99 Seal 2
100 Intake Manifold 1
101 Check Valve 1
102 Wire Clip 1
103 Wire 1
104 Hook 1
