Fostex 6301BEAV - PCB Assembly and Parts List; PowerAmp PCB Components; LineAmp PCB Components

6
6301B/BX/BE
3. PCB ASSY AND PARTS LIST
PCB Assy PowerAmp 8274216000
Ref. No. Part No. Description B BX BE
C001 8232050471 CAP, CER, 50V, 470pF, 5% * * *
C002 8232098105 CAP, ALU, 50V, 1µF, 20% * * *
C003, 004 8232097227 CAP, ALU, 35V, 220µF, 20% * * *
C005 8232095476 CAP, ALU, 16V, 47µF, 20% * * *
C006 8232026123 CAP, PES, 50V, 0.012µF, 5% * * *
C007 8232026104 CAP, PES, 50V, 0.1µF, 5% * * *
C008, 009 8232074000 CAP, CER, 50V, 0.1µF, 20% * * *
C010 8232026103 CAP, PES, 50V, 0.01µF, 5% * * *
C011, 012 8232133478 CAP, ALU, 35V, 4700µF, 20% * * *
D001 8234001607 D, STACK, 2W02G * * *
R001 8230004102 RES, CARBON, 1/4W, 1K, 5% * * *
R002 8230004563 RES, CARBON, 1/4W, 56K, 5% * * *
R004 8230004122 RES, CARBON, 1/4W, 1.2K, 5% * * *
R005 8230004563 RES, CARBON, 1/4W, 56K, 5% * * *
R006 8230004153 RES, CARBON, 1/4W, 15K, 5% * * *
R007 8230004102 RES, CARBON, 1/4W, 1K, 5% * * *
R008 8230004100 RES, CARBON, 1/4W, 10, 5% * * *
R010 8230004222 RES, CARBON, 1/4W, 2.2K, 5% * * *
U001 8234045600 IC, PowerAmp, TDA2050 * * *
PCB Assy LineAmp 8274211000
Ref. No. Part No. Description B BX BE
C021, 022 8232095106 CAP, ALU, 16V, 10µF, 20% *
C021, 022 Jumper *
C023 8232095106 CAP, ALU, 16V, 10µF, 20% * *
C024, 025 8232096476 CAP, ALU, 25V, 47µF, 20% * *
R021 8230004103 RES, CARBON, 1/4W, 10K, 5% *
R022 8230004103 RES, CARBON, 1/4W, 10K, 5% *
R022 8230004102 RES, CARBON, 1/4W, 1K, 5% *
R023 8230004392 RES, CARBON, 1/4W, 3.9K, 5% * *
R024 8230004103 RES, CARBON, 1/4W, 10K, 5% *
R024 Jumper *
R025 8230004392 RES, CARBON, 1/4W, 3.9K, 5% * *
R026 8230004103 RES, CARBON, 1/4W, 10K, 5% *
R027 8230004392 RES, CARBON, 1/4W, 3.9K, 5% * *
R028, 029 8230004102 RES, CARBON, 1/4W, 1K, 5% * *
U002 82360212000 IC, Analog, NJM4560DX * *
DZ001, 002 8234503959 D, ZENER, MTZ J 15C * *
CN002 8245053003 Conn, JACK, 8263, 3P, WHT * *
JK001 8245103000 Conn, Phone, B/BX/BE *
JP006, 007 Jumper *
