9
Model VC-8 Owner’s Manual
< INPUT x 8 >
• Connector : RCA pin jack (x 8)
• Input Impedance : 20k or more
• Input Level : -10dBV
< OUTPUT x 8 >
• Connector : RCA pin jack (x 8)
• Load Impedance : 10k or more
• Output Level : -10dBV
< DATA IN/OUT >
• Connector : OPTICAL (x 2)
• Format : 1. IEC60958 (S/P DIF)
2. Alesis Proprietary Multi Channel Optical Interface
(Switched to 1 or 2.)
< WORD IN >
• Connector : BNC type (x 1)
• nput Level : TTL Level
• Input Impedance : 75 (terminator switched On/OFF)
< OTHERS >
• AD : 20 bit 64 times over sampling modulation
• DA : 20 bit 128times over sampling modulation
• Sampling Frequency : INT mode : 44.1kHz
: OPTICAL/WORD mode : 32 ~ 48kHz
• Total Harmonic distortion : 0.008%(@ 1kHz, TYPICAL)
• Dynamic Range : 96dB (TYPICAL)
< GENERAL >
• Dimensions : 220 (W) x 43 (H) x 180 (D) mm
• Weight : 1.0kg (Excluding accessories)
• Power Supply : DC12V, 600mA,Exclusive AC Adaptor (AD-12A)
* Specifications and appearance are subjects to change without notice for product improvement.
* Adat and the
OPTICAL
marks are trademarks of Alesis Corporation.
Specifications
