3-4. Fader Check
While holding down both the PAN/EQ and EFF/AUX keys, press the FADER ADJUST key. The LCD digits will
indicate the current level of input, master faders and data wheel. The level of input & master faders will vary from 00
~ 99. The data wheel level will vary from 0 ~ 9. Check if the level will vary when operating the faders and wheel.
Pressing the EXIT key will put back the VM88 to the normal mode display.
OL
1
6
12
24
48
14678LR532
MAX
R
MIN
L
MID HILOPA N
A1 A2E2E1
SCENE NO.
OL
-3
-6
-9
-12
-18
-24
-36
RL
OPTICAL
CH
MASTER
44.1kHz
CH1 FADER LEVEL
CH2 FADER LEVEL
CH3 FADER LEVEL
CH4 FADER LEVEL
DATA WHEEL LEVEL
CH5/6 FADER LEVEL
CH7/8 FADER LEVEL
MASTER FADER LEVEL
3-2. Battery Check
While holding down both the PAN/EQ and EFF/AUX keys, press the EFF 2 key. The LCD display will show the
voltage of the memory backup battery inside the VM88 for about a second, and then return to the normal display
mode. If the voltage falls below 2.2V, the message “BattEmpty” will appear with powering on. When this message
appears, the battery has to be replaced with the new one.
OL
1
6
12
24
48
14678LR532
MAX
R
MIN
L
MID HILOPA N
A1 A2E2E1
SCENE NO.
OL
-3
-6
-9
-12
-18
-24
-36
RL
OPTICAL
CH
MASTER
44.1kHz
OL
1
6
12
24
48
14678LR532
MAX
R
MIN
L
MID HILOPA N
A1 A2E2E1
SCENE NO.
OL
-3
-6
-9
-12
-18
-24
-36
RL
OPTICAL
CH
MASTER
32kHz 48kHz44.1kHz
DIGITAL
REMAIN ABS
LOC MTC IN
MH
: Blinking
MTC
3-3. Display Check
While holding down both the PAN/EQ and EFF/AUX keys, press the EXIT key. The LCD segments as well as the
LEVEL / FADER ADJUST, EFF/AUX, PAN/EQ, RECALL, STORE, EFF1 / 2 keys / self-illuminating switch and
PHANTOM LED will start blinking. Check if they are correctly blinking. Pressing the ENTER key will change the
blinking pattern. Pressing the EXIT key will put the VM88 back to the condition right after powering on.
