6
Installing the battery
1. Detach the battery band that
holds the battery in place.
2. Hold the battery band back to
keep it from going inside the
Fotokite’s main body.
3. Slide the battery in from the
side. Position it centrally
to ensure the ight frame is well
balanced.
4. Pull the battery band over the
battery, and secure it to the
yellow hook at the bottom of the
ight frame payload.
5. Plug in the battery connector
as shown above.
Battery band
