Foundations Gaggle 4 Buggy - Hardware List

U
AB20105_G4
K
M
N
O
Q
R
S
T
P
K. 5/16” - 18 Hex Head 2 1/2” Bolt
M. 5/16” - 18 Hex Head 1 3/4” Bolt
N. 5/16” - 18 Hex Head 1 1/2” Bolt
O. 5/16” - 18 Hex Head 7/8” Bolt
P. Retaining Pin
Q. 5/16” - 18 Acorn Nut
R. Cap Nut
S. Cap Nut Washer
T. 7/16” Washer
U. Assembly Washer
HARDWARE LIST
Part Description Part Number Quantity
11200500
11200502
11200503
11200504
11200682
11200506
11300070
11200320
11200275
11200507
1
4
4
4
2
1
1
1
2
12
4
