Fox F11-951 User Manual

36
1. Electrical connections
F 11-951
F 11-991
Motor
230 V / 50Hz / 350 W
230 V / 50 Hz / 500 W
2. Drilling capacity
F 11-951
F 11-991
Drilling capacity in steel (mm)
13
16
Distance spindle - column (mm)
102
126
3. Morse cone
F 11-951
F 11-991
Joining lenght
50
60
Morse cone
MK 2
MK 2
4. Workbench drilling
F 11-951
F 11-991
Workbench angle
45°
45°
Rotation of the workbench on the
base
360°
360°
Workbench dimensions (mm)
195 x 170
240 x 200
Workbench dimensions with
extensions (mm)
280 x 170 330 x 200
Spindle capacity – workbench (mm)
13
16
Distance between the grooves
(mm)
105
-
5. Measurements
F 11-951
F 11-991
Height (mm)
730
850
Depth (mm)
410
520
Width (mm)
240
300
Total weight (kg)
30
43
Coupling diameter
50
60
Max distance morse cone – drilling
workbench
300 400
6. Necessary working area
F 11-951
F 11-991
Height (mm)
2000
2000
Depth (mm)
1800
1900
Width (mm)
1200
1200
7. Drilling speed
F 11-951
F 11-991
Spindle rotational speed (RPM)
580
850
1220
1650
2650
425 – 560 – 645
730 - 790 – 860
1275 – 1350 – 1600
1710 – 2060 - 2545
8.Laser pointing device
F 11-951
F 11-991
Rating
2
2
Power
< 1 mW
< 1 mW
Laser wave length
650 nm
650 nm
9.Vibrations
F 11-951
F 11-991
Measured level
< 2,5 m/sec2
< 2,5 m/sec2
10. Working conditions
F 11-951
F 11-991
Temperature
5-35° C
Air humidity margin
25-80%
TECHNICAL SPECIFICATIONS

Fox F11-951 Specifications

General

Brand	Fox
Model	F11-951
Category	Power Tool
Language	English
