UNPACKING THE DUST COLLECTOR
Unpack your dust collector carefully, taking care with the loose parts.
Note : if any parts are damaged or missing, do not connect the machine to the power and do not switch it on until the
missing/damaged parts are replaced.
Do not throw away the cardboard box until you are sure the machine is working correctly.
Check that the following parts are included:
A. Hose
B. Collector body and fan/motor assembly
C. Collector
D. Base plate
E. Upper bag support
F. Collector support
G. Inlet
H. Two filter bags
I. Packing
J. Four casters
K. Nuts, screws, washers, spring washers and
wrench
L. Outlet
M. Two hose clamps
N. Handle
O. Bag clamp
P. Collector block
