605-01-278 5
NOTICE: Medium-strength thread-lock is recommended on all bolts.
1. Please read the installation guidelines on page 4 for instructions on how to properly lift and secure
the vehicle.
OEM BUMP STOP REMOVAL
FRONT BUMP STOP INSTALLATION
2. Remove both front wheels.
3. Disconnect the battery.
4. Disconnect any necessary components in order for springs to be free from upper mount.
Remove the front coil springs. A professional spring compressor is recommended and may be necessary
in some applications.
5. Remove factory bump stop by prying it free from the bump stop holder.
Fig. 1: Mark the cut line. Passenger side shown.
2.75”
FOX BUMP STOP PREPARATION
6. Use painters tape and mark the cut line 2.75”
above the bottom of the OEM bump stop holder
(Fig. 1).
