Quick Guide 06.2007 QG EVE0105 B-(en)
SRD991 Intelligent Positioner
These instructions are to be used as a guide for quick start-up. For more detailed information please refer
to the standard documents “Master Instructions” and “Product Specification Sheet”. These can be found
on our Website www.foxboro-eckardt.com
Versions with LCD (and LEDs):
SRD9
91 - all versions -
1. MOUNTING TO ACTUATORS
During operation the flat side of the spindle 9 on the back of the positioner must always point towards
the arrow 26. The working angle around this position is ±45º.
'
$
'
$
