Foxconn 5G + 4G AIO Small Cell User Manual

5
1.2 Product Specifications
Table 1 Product Specifications
Specification
Description
4G + 5G dual mode small cell
Operating
Frequency
▪ 26.5 ~ 29.5 GHz (Band n257/n261 for 5G)
▪ 3550 ~ 3700 MHz (Band 48 for 4G)
TX Power
▪ EIRP 50.6 dBm @ 5G mmwave
▪ EIRP 24 +- 2 dBm for 4G
RF Bandwidth
▪ 20MHz @ 4G
▪ 400MHz @ 5G
Activate users
▪ 64 ~ 128
Duplex technique
▪ TDD
Throughput
▪ 6.5 / 3.2 Gbps DL/UL
Compute & Storage
Main chip
▪ NPU LX2160 + FSM10055 + QTM10028 on 5G
▪ FSM9955 + FTR8900 on 4G
Flash/ Memory
▪ 64GB
Antenna Interface
GPS Antenna
Connector
▪ SMA female connector
WAN Interface
Ethernet
▪ 100/1000/10000 Mbps
Power
Power Input
▪ 48V DC
Power
Consumption
▪ Maximum 150 watts
Antenna
5G
▪ 64 dual polarized antennas
LTE
▪ 6 +- 1dBi
GPS
▪ 1 active antenna with SMA type
