1-2 Layout
Note : The above motherboard layout is for reference only, please refer to the physical
motherboard for detail.
1. 8-pin ATX 12V Power Connector
2. PCI Express x16 Slots
3. PCI Express x1 Slots
4. PCI Slots
5. Front Audio Connector
6. Speaker header (Buzzer connector)
7. MFG Jumper
8. Front USB Connectors
9. COM1 Connector
10. Clear CMOS Jumper
11. Front Panel Connector
12. SATA Connectors
13. Chassis Intrusion Alarm Header
14. Chipset: Intel
®
P67
15. IrDA Connector
16. SYS_FAN1/2 Header
17. IDE Connector
18. 24-pin ATX Power Connector
19. DDR3 DIMM Slots
20. CPU_FAN Header
21. LGA1155 CPU Socket
1
15
5
18
20
19
2
2
17
4
6
7
10
12
21
3
8
9
11
16
14
13
